Scott Drake 1966 Ford Mustang Exploded View Illustration Manual MP-347

Scott Drake 1966 Ford Mustang Exploded View Illustration Manual MP-347
$24.99 ea
NEWOut of stock with our supplier as of 04/03/2024
Model: 3937497
Select a Vehicle or refer to the Vehicle Fitment Tab below to verify that this part fits your vehicle.
STANDARD
DELIVERY
STORE PICKUP
[More Info]
Shows all Ford illustrations, easy to read, great for seeing how assemblies fit together. Also lists basic part numbers.

About Scott Drake

Scott Drake is the world's largest manufacturer and supplier of reproduction parts for classic Mustangs. Featuring thousands of quality products, Scott Drake is also one of the largest manufacturers of Ford-licensed parts. Scott Drake products are available through Mustang parts retailers, distributors, and restoration shops world-wide.

Vehicle Fitment:

The Vehicle Fitment Guide is to be used as a general reference. The data has been provided by our suppliers and manufacturers and may contain errors or incorrect data. Always refer to a professional to verify correct fitment for your vehicle.
Make Model Submodel Years Engine
Ford Mustang Base 1966 4.7L / 289 / V8
3.3L / 200 / L6
Ford Mustang Shelby GT-350H 1966 4.7L / 289 / V8
Ford Mustang Shelby GT-350 1966 4.7L / 289 / V8

Specifications:

Cover Type Soft
Emission Code 6
Length 10 7/8
Page Quantity 80
Part Type Technical Specification Book
Product Type Technical Specification Book
Proposition 65 www.P65Warnings.ca.gov
Width 8 1/4
